This model of industrial ribbon mixer machine is composed of a container, spiral stirring blades, and transmission components; The inner spiral transports materials from both sides of the center to create convective mixing, and the outer spiral collects materials from both sides to the center. Spiral blades are typically manufactured in two or three layers.
technical parameters
|
Model |
Total volume (m3) |
Loading coefficient |
Power(kw) |
Overall size(mm) |
Weight(kg) |
|
WLDH-0.1 |
0.1 |
0.4-0.8 |
3 |
1190*740*770 |
330 |
|
WLDH-0.2 |
0.2 |
0.4-0.8 |
3 |
1550*700*800 |
420 |
|
WLDH-0.3 |
0.3 |
0.4-0.8 |
4 |
2030*630*980 |
720 |
|
WLDH-0.5 |
0.5 |
0.4-0.8 |
7.5 |
2320*730*1130 |
980 |
|
WLDH-1 |
1 |
0.4-0.8 |
11 |
2800*920*1320 |
1700 |
|
WLDH-1.5 |
1.5 |
0.4-0.8 |
11 |
3180*1020*1550 |
1800 |
|
WLDH-2 |
2 |
0.4-0.8 |
15 |
3310*1120*1640 |
2100 |
|
WLDH-3 |
3 |
0.4-0.8 |
18.5 |
3750*1290*1820 |
3000 |
|
WLDH-4 |
4 |
0.4-0.8 |
22 |
4220*1400*1990 |
3980 |
|
WLDH-5 |
5 |
0.4-0.8 |
22 |
4220*1500*2100 |
4620 |
|
WLDH-6 |
6 |
0.4-0.8 |
30 |
4700*1610*2260 |
6180 |
|
WLDH-8 |
8 |
0.4-0.8 |
37 |
4420*2150*2470 |
8200 |
|
WLDH-10 |
10 |
0.4-0.8 |
45 |
5520*2960*2720 |
8920 |
|
WLDH-12 |
12 |
0.4-0.8 |
45 |
5720*3010*2840 |
9520 |
|
WLDH-15 |
15 |
0.4-0.8 |
55 |
5840*3540*2940 |
9950 |
|
MARKS: There are many kinds of Food & Medicine & Chemical Processing Machine for your choice, please be free to contact with us. |
|||||
Product details：
According to the needs, the horizontal ribbon blender machine can be customized with carbon steel, manganese steel, 304 stainless steel, 316L stainless steel, 321 stainless steel, and other materials, and different materials can also be used in combination; When selecting equipment materials, distinguish between parts that come into contact with materials and parts that do not come into contact with materials; Functional coatings or protective layers such as anti-corrosion, anti bonding, isolation, and wear resistance can also be added specifically inside the mixer; Stainless steel surface treatment can be divided into sandblasting, wire drawing, polishing, mirror surface and other treatment methods, and can be applied to different parts of use separately; Install heating or cooling devices; The internal spiral belt is made according to different materials; The discharge port can be made according to demand.
our service
Besides our existing molded products, Wuxi Deiichen also can accept customized products as different requirements. We control the product quality critically for every step during the manufacturing. We offer technical support that is second to none.
