Double Swing Granulator

The Double Cylinder Swing Granulator machine can make mixed powder materials into particles, and can also crush block dry materials into desired particles. The swinging granulator is suitable for batch production in pharmaceutical factories, chemical factories, food factories, scientific research institutions, and laboratories.

The material contact parts are all made of stainless steel material, with a beautiful and elegant appearance, easy to clean and operate, and low energy consumption.

1. Gas sealing: The two ends of the particle shaft of this mechanism adopt a gas sealing structure, effectively preventing materials from entering the sealing cover.

2. Explosion proof: Various models can be customized with explosion-proof models to meet the production environment that requires explosion proof. 3. High power: upgraded transmission gearbox and motor, suitable for granulation of various powder products and high density materials.

4. Heavy duty: The ointment machine adopts a reinforced transmission system with high power, which meets the requirements of ointment materials granulation.

The entire machine of the swinging particle machine is made of stainless steel, and the swinging particle machine mainly consists of a feeding hopper, a roller, a screen, and a mechanical transmission system. When it works, the mechanical transmission system drives the drum to rotate. There are seven trapezoidal shaped "scrapers" on the drum, and under the drum, there is a sieve mesh with a pipe clamp clamped by the wheel. The agglomerated material is added by the feeding hopper. Due to the positive and negative rotation of the drum, the scraper produces compression and shear effects on the wet material. The material is squeezed through the sieve mesh to form particles. When the double swing granulator machine is running, The tightness of the feeding mechanism and screen position directly affects the quality of the particles produced. When there is a large amount of material added in the feeding hopper and the screen is clamped loosely, the rotation of the drum can increase the number of times soft materials pass through the screen, making the particles hard. The particle size distribution obtained by the swinging particle mechanism is generally uniform, which is conducive to the uniform drying of wet particles.

Its main characteristics are that the rotational speed of the rotating drum can be adjusted, the screen is easy to load and unload, and the tightness can also be adjusted appropriately. The mechanical transmission system is sealed inside the body and is equipped with an adjustment system, which increases the service life of the machine components. However, due to the fact that the granulation process is directly compressed by the drum to form particles, the friction force of the material on the screen is relatively high. When using metal screens, it is easy to cause metal pollution. However, nylon screens need to be replaced frequently due to their easy damage, and attention should be paid when using them.
